GA 583

Medium Back Chair, Fixed PP Arm, Gas Lift,

Nylon Base, Seat & Back Mesh Tapestry

Enter Quantity

Add To Enquiry Cart

Overall Dimensions (in mm)
Overall Height	960 mm	Overall Depth	580 mm
Seat Depth	485 mm	Back Height (From Seat)	550 mm
Seat Width	495 mm	Back Size	600 mm
Seat Height	460 mm	Back Width	490 mm
Outer Width	625 mm	Inner Width	450 mm
Height Adj. (Gas Lift)	120 mm	Gas Lift Type	BIFMA standard class - 3

Seat & Back
Seat Ply Type	Hot Pressed	Back Ply type & Model No	NA
Seat Ply thickness	15 mm	Back Ply thickness	NA
Seat foam type, thickness & density	Urethane foam, (25+19)mm thick of density 40Kg/m³	Back foam type, thickness & density	NA
Seat Cover	NA	Back Cover	PP Net Cover
Seat Tapestery, Colour & thickness	Foam net, black, GKN-307, 0.9mm, 300GSM	Back Tapestery, Colour & thickness	Net, black, GKN-308, 0.8mm, 535GSM
Seat & Back Type	Individual

Armrest
Armrest Type, Model No	Fixed	Armrest Material	PP Arm
Armrest Length	265 mm	Armrest Width	85 mm
Armrest Height	170 mm	Armrest fixing type	Fixed with seat
Arm top finishing	NA	Arm Movement	NA

Mechanism & Features
Chair Mechanism type	Synchro Knee Tilt	Revolving/ Fixed	Revolving
Type of Locking	Multipoint Locking	Tilt Tension Adj.	Yes
Lumbar Support	Yes	Spine joining seat & back	Yes
Head rest provided at back	NA

Chair Understructure
Pedestal Material	Nylon	PCD of Pedestal	650 mm
Cladding & finishing	NA	Types of Castors	50mm twin wheel, Nylon, Injection moulded
Legs/Support in case of fixed chairs	NA
