GA 502 C

Medium Back Chair, Fixed PP Arm, Gas Lift,

Nylon Base, Seat & Back Mesh Tapestry

Enter Quantity

Add To Enquiry Cart

Overall Dimensions (in mm)
Overall Height	960 mm	Overall Depth	600 mm
Seat Depth	500 mm	Back Height (From Seat)	555 mm
Seat Width	465 mm	Back Size	610 mm
Seat Height	435 mm	Back Width	475 mm
Outer Width	620 mm	Inner Width	450 mm
Height Adj. (Gas Lift)	65 mm	Gas Lift Type	BIFMA standard class - 3

Seat & Back
Seat Ply Type	Hot Pressed	Back Ply type & Model No	NA
Seat Ply thickness	18 mm	Back Ply thickness	NA
Seat foam type, thickness & density	Moulded PU Foam having density 45 Kg/m³	Back foam type, thickness & density	NA
Seat Cover	NA	Back Cover	NA
Seat Tapestery, Colour & thickness	Foam net, black, GKN-307, 0.9mm, 300GSM	Back Tapestery, Colour & thickness	Net, black, GKN-308, 0.8mm, 535GSM
Seat & Back Type	Individual

Armrest
Armrest Type, Model No	Fixed	Armrest Material	PP Arm
Armrest Length	270 mm	Armrest Width	85 mm
Armrest Height	170 mm	Armrest fixing type	Fixed with seat
Arm top finishing	NA	Arm Movement	NA

Mechanism & Features
Chair Mechanism type	Knee Tilt	Revolving/ Fixed	Revolving
Type of Locking	Multipoint Locking	Tilt Tension Adj.	Yes
Lumbar Support	Yes	Spine joining seat & back	Yes
Head rest provided at back	NA

Chair Understructure
Pedestal Material	Nylon	PCD of Pedestal	700 mm
Cladding & finishing	NA	Types of Castors	50mm twin wheel, Nylon, Injection moulded
Legs/Support in case of fixed chairs	NA
